Screw Type Plastic Process Cooling Equipment System
| Cooling capacity: (kw) | 438 |
| Input power: (kw) | 85.8 |
| Flow of chilled water: (m3/h) | 75.3 |
| Flow of cooling water: (m3/h) | 90.1 |
| Number of Circuit | 1 |
| Evaportor inlet/outlet pipes dia: | 4” |
| Condenser inlet/outlet pipes dia: | 4” |
| Water Side Max Pressure(Mpa) | 1 |
| Capacity Control(%): | 0, 25%, 37.%, 50%,62.5%,75%,87.5%,100 % |
| Power supply: | 380v-3ph-50hz |
| Compressor: | Screw type |
| Compressor Qty | 1 |
| Condenser: | Shell and tube type |
| Evaporator | Shell and tube type |
| Weight | 1860kgs |
| Protection devices: | Reverse, over-flow, Exhaust air temp, high-low temp/pressure protection water flow protection. Anti-frozen protection. |
1. Installed with import compressors, highly efficient shell condenser and evaporator, excellent cooling, quiet and low electricity consumption.
2. Microprocessor control, easy to operate.
3. Installed with current overload protector, high and low pressure switch, electronic timer delay, fault display system.
4. Screen liquid crystal display of chill water out let and inlet with temperatures setting.
5. Single or double compressors combination unit available.
6. the temperature of leaving water can be control within more than -5°C.
7. Water Cooled unit with two refrigerating loop circuit, which can interchangeably and independently run.
8. High efficiency air condenser and Large wind volume axial flow design
Product Main View.
Applications:
Water Chillers are applicable to places such as Shopping mall, commercial builing Workship, hotels, restaurants, recreational centers, hospitals, dining halls, offices, cinemas, factories, and supermarkets, especially to those rising high requirement on noise reduction and ambient environment.
Notice: Any Non-standard design water chiller welcome to send us details information. OEM and Customize service available.
